Rotary Nickel Screen Printing Mesh
Rotary Printing
Product advantage:
More tough and tensile, safely operation and multiple use
Good symmetrical, good conglutination function of photosensitive medicament
Orderliness and accurate screen caves, good dye output and osmotic function
Higher strength, longer life screen
Nickel screen for screen printing machine
Packaging Detail:packaged in plywood case or carton box
Delivery Detail:Within 10-15 days
More tough and tensile, safely operation and multiple use
Good symmetrical, good conglutination function of photosensitive medicament
Orderliness and accurate screen caves, good dye output and osmotic function
Higher strength, longer life screen
Nickel screen for screen printing machine
Packaging Detail:packaged in plywood case or carton box
Delivery Detail:Within 10-15 days
Quantity:
Product name：Nickel rotary mesh
Enyang provide rotary screen ranges as follow:
Dyestuff saving by High mesh screens: due to the high density of holes, unique involuted hole shape, and minimized nickel dam, the coverage of dyestuff paste on the fabrics has largely increased compared with conventional Penta screens. For the same amounU, intensity of dyestuff deposit on surface of fabric, less squeegee/ magnetic roller pressure is required; as a result, substantial saving on dyestuff paste is achieved. Experiments have proved that up to 19% of paste volume can be saved at multiple printing mills around the world.
Nickel mesh is an accessory product specially suitable for roller round screen printing machine/rotary screen printing machine . We can provide you with nickel wire mesh suitable for blanket printing or nicke mesh screen suitable for wallpaper printing. We assure you that the nickel mesh we provide is pure nickel mesh screen and different from ordinary nickel mesh, with the characteristics of long service life and good toughness. Its biggest advantage is that it can be repeated 5-6 times.
Mesh Count:25,30,40,50,60,70,80,100,125,135,155,165,up to 195 mesh count.
Screen Repeat:640,688,725,819/820,914,1018,1206,1450,1680mm
Length:1000 mm to 3500 mm. which are of high quality and can replace the similar products as well from Europe.
All other specifications could be customized. Nickel rotary mesh
All other specifications could be customized. Nickel rotary mesh
Standard Nickel Screen | |||
Repeat(mm) | 530/640/688/725/819/914/1018 | ||
Length(mm) | 1410-3500 | ||
MESH COUNT | THICKNESS(um) | OPEN AREA(%) | DIAMETER(um) |
25 | 160-165 | 30-32 | 720 |
40 | 145-150 | 28-30 | 318 |
60 | 115-120 | 18-20 | 161 |
70 | 110-115 | 16-18 | 131 |
80 | 110-155 | 16-18 | 105 |
100 | 105-115 | 15-17 | 74 |
105 | 105-115 | 15-17 | 94 |
125 | 100-105 | 14-16 | 79 |
125V | 100-105 | 14-16 | 79 |
135 | 100-105 | 13-15 | 72 |
135V | 100-105 | 13-15 | 72 |
155 | 100-105 | 12-13 | 60 |
165 | 100-105 | 12-13 | 71 |
All"V type screen, the hole arrangement angle is 45°C, especially suitable for geometry printing, eg-square and line, all screen can be repeatedly used for 5-7 times. | |||
SP Screen: Big open area and relatively less hole, especially suitable for decoration coating, dot printing
CH Screen: Suitable for medium or thicker printing
LR Screen: Closed drawing coating, light coating, artificial leather, wall paper and floor
Rotary screen mesh Product advantage:
Three Main Advantage of Producing Nickel screen mesh:
1. Without use of saccharin as additive, a screen exhibits good property of resilience, softness of screen is eliminated, and therefore creases are depressed during the prepress and printing processes, which provides convenience/efficiency for the operators during the handling and use of screens.
2. Brittleless: use of sulphur-free additive at screen-making process enables non-existence of brittleness of screens during/after the rounding and polymerization process. Brittleness is the main cause of screen crack and damage on the rotary printing machine win operation. A convenient way to test the brittleness is the so-called"lighter test": a piece of screen sample burnt by lighter flame for 10 seconds, bend the screens sample to see if it breaks at the burnt spot.Can endure 6-7 times stripping by waterjet or LEN.
3. Narrow tolerance of open area(+/-0.5%) and thickness(+/-3 microns) safeguard high consistency of screens, whichminimizes the color difference among right, middle and left side of printing width. In addition, ifs worry free to pick screens from difference batches due to high level of quality control on consistency.
